BetoBoard® A1 Class Fiber Cement Floor Boards
Dryscreed boards T&G or Easy Overlap Edges
BETOBOARD®️ boards are asbestos free, calcium silicate, cement bonded. These multi-purpose boards are easy to handle and offer a superior combination of enhanced technical properties for strong, mechanically self-supporting constructions.
BETOBOARD®️ boards are hygroscopic and vapour permeable. Moisture content is therefore automatically regulated by the applicaton environment.
- · Cement fiber boards with Class A fire and impact sound noise protection
- · Optimal thermal insulation with maximum energy efficiency
- · Easy laying of floor coverings of any kind directly on the panels
- · Perfectly suitable for laying on underfloor heating
- · Impact resistant
BETOBOARD®️ Flooring Element is the best choice for renovating your floor. By laying the screed panels under your actual floor covering, you improve the feeling of living and protect your floor from various types of damage.
BetoBoard Products
A1 Class Easy Overlap FibreCement Floorboards
SECTORS:•Renovations, Student accomodation and schools• Social housing• Commercial and industrial buildings• Hospitals and nursing home
BetoBoard FB-18
Non-flammable (A1)
BetoBoard FB-20
Ensure optimum thermal insulation
BetoBoard FB-22
Suitable for laying on underfloor heating
BetoBoard FB-28/32
Easy processing, easy install
BetoBoard FB-30
Accoustic
Wall Board 8-10-12m
Tile Backer board 8mm. 10mm. 12mm
BetoBoard Fb-18 Construction Floor Boards A1 Class
BetoBoard supplied by Atako Limited is designed to be easy to install and use.
BetoBoard fibercement screed elements consist of one 18mm Tongue and Groove or Easy Overlap Edges
BetoBoard fibercement screed elements consist of one 18mm Tongue and Groove or Easy Overlap Edges
BetoBoard are suitable for underfloor heating and sound applications, feature a tongue and groove edge detail (no screws) or overlay system and benefit from high impact resistance.
Betoboard increases the efficiency of an under floor heating boards system due to its low thermal resistance and rapid heat transfer characteristics.
BetoBoard fibercement screed elements consist of one 18mm Tongue and Groove or Easy Overlap Edges
BetoBoard fibercement screed elements consist of one 18mm Tongue and Groove or Easy Overlap Edges
BetoBoard fibercement screed elements consist of one 18mm Tongue and Groove or Easy Overlap Edges
Enhances acoustic performance: with wood acoustic technology to improve sound isolation.
- Accepts multiple floor finishes: as a robust, impact resistant overlay solution, BetoBoard offer full flexibility when it comes to choosing your ideal floor covering. From textile and laminate to tile and wood, the possibilities are vast.
Overlap System or Four Side Tongue and Groove
Suitable for Heavy Traffic
BetoBoard FB Production Tolerances
Thickness 18 mm Size Tolerances ± 1 mm
Diagonal Tolerances ≤ 2 mm Thickness Tolerances ± 0,9 mm
Board Sizes 600 x 1200 mm
Ideal substrate for Tiles
A thick, durable compressed structural flooring substrate
BetoBoard compressed Panel is a compressed fibre cement structural flooring substrate for ceramic tile finishes over timber or lightweight steel floor joists; it’s made from highly durable compressed fibre cement.
...
Betoboard Fb-20 Overlap System FloorBoards 600x1200 mm
BetoBoard screed elements are ideally suited for many tasks: fire protection, noise protection,
BetoBoard screed elements are ideally suited for many tasks: fire protection, noise protection,
BetoBoard screed elements are ideally suited for many tasks: fire protection, noise protection,
- Quick and easy to install: twin layered interlocking floating floors which can be used in a variety of applications. There are less drying times, your floor is ready to work on the next day!
- Boost underfloor heating: offer minimal thermal resistance for better underfloor heating systems
As an internal substrate for tiled wet-area floors and an external substrate for tiled balconies and verandas, in both residential and commercial buildings. It’s a durable, moisture-resistant alternative to particleboard and plywood substrates, and a lightweight alternative to concrete. .....
.
The combination of natural fiber boards and the factory-applied insulation with Stonewool
BetoBoard screed elements are ideally suited for many tasks: fire protection, noise protection,
BetoBoard screed elements are ideally suited for many tasks: fire protection, noise protection,
- Comes in a handy board size: 1200 x 600 mm, making the boards easy to carry and lay. Also offered in five thicknesses: 18 mm 20 mm, 25 mm 30 mm and 32 mm
- Non-combustible: A1 fire rated board
- Comes in to Sizes: 1200x600 mm or 600x600 mm.
As Tile Backer Board in various sizes also available
Suitable for Walls and Partitions
Overview
Product Code: FB-20 Length (mm): 1200mm Width (mm): 800mm Thickness (mm): 8-10-12mm Mass (kg/m2): 13
Tolerances <2 %
..
Betoboard Fb-22 extreme durable and easy to install
Easy to cut and install, can be cut with skill saw Interlocking edges -
Easy to cut and install, can be cut with skill saw Interlocking edges -
Easy to cut and install, can be cut with skill saw Interlocking edges -
Low thermal resistance (0.045/m2/kW) .
High thermal conductivity (0.40W/mK).
Low thermal expansion.
Only 18mm thick.
Doesn’t contract or expand like chipboard when exposed to water.
High impact resistance.
Tongue and groove edge detail – no screws required.
Quick and easy to install.
Ideal for bathrooms and kitchens - accepts ceramic tiles directly
Easy to cut and install, can be cut with skill saw Interlocking edges -
Easy to cut and install, can be cut with skill saw Interlocking edges -
Fire Resistance
A1 non-combustible fire rated to EN1305-1:2007 + A1:2009.
Water and Moisture Resistant
BetoBoard provides excellent resistance to the harmful effects of moisture and water. Acoustic Properties
BetoBoard has excellent sound absorption characteristics making them ideal for reducing sound transmission.
They can be used coupled with acoustic resilient layers.
Water and Moisture Resistant for Wetrooms
Suitable for In or Outside Wet Areas
BetoBoard FB 18 Production Tolerances
Thickness 22 mm
Size Tolerances ± 1 mm
Diagonal Tolerances < 2 mm
Thickness Tolerances ± 0,9 mm
Available Board Sizes 600 x 1200 mm
600 x 600 mm
,
Suitable for Raised Access Flooring
• Large-size, self-supporting
• High mechanical strength
• Defined heat transmission for comfortable room temperatures
• Good sound insulation properties
• A1, non-combustible (EN 13501)
• Easy to shape and work
• Good chemical resistance
• Hygroscopic and vapour-permeable
BetoBoard Fb-28 Overlap waterproof and 90 Minute Firepoof
4 x lower thermal resistance than chipboard Only 28 mm thick dry screed board
4 x lower thermal resistance than chipboard Only 28 mm thick dry screed board
4 x lower thermal resistance than chipboard Only 28 mm thick dry screed board
BetoBoard dry screeds impress with their low installation height and low weight. Because this makes the dry screed also suitable for old buildings in need of renovation, which have limits in terms of their load-bearing capacity. In addition, BetoBoard dry screeds are the right choice when there is time pressure and a floor needs to be built on quickly.
High thermal performance High acoustic performanace
4 x lower thermal resistance than chipboard Only 28 mm thick dry screed board
4 x lower thermal resistance than chipboard Only 28 mm thick dry screed board
A1 non-combustible fire-rated fibre cement board Four sided tongue and groove flooring system with sound, thermal and moisture resisting properties.
BetoBoards can save up to 15% on energy bills per annum when compared with a traditional wet screed boards.
Suitable For High Traffic Areas
Suitable for Ceramics Hartwood and Vinyl
Working & processing
Woodworking machinery with hard metal-tipped tools can be used for producing and shaping cut sections.
When cutting to size, the maximum workplace concentration values for inhalable dust must be observed.
Improved living quality
BetoBoard FB Production Tolerances
Thickness 18 mm
Size Tolerances ± 1 mm
Diagonal Tolerances ≤ 2 mm
Thickness Tolerances ± 0,9 mm
Board Sizes 600 x 1200 mm or 600 x 600 mm
,,,,
BetoBoard Fb-32 Fibre Cement Construction Board Fireclass
BetoBoard accept direct application of various floor finishes including ceramic tiles, vinyl or hard
BetoBoard accept direct application of various floor finishes including ceramic tiles, vinyl or hard
BetoBoard accept direct application of various floor finishes including ceramic tiles, vinyl or hard
Mezzanine flooring• Balconies and loft conversions• Bathrooms and wetrooms
• Enhances underfloor heating systems
Suitable for
Renovation, fire protection, noise protection, impact sound insulation, thermal insulation, underfloor heating
BetoBoard feature easy to install overlaying edges, and doesn't contract or expand when exposed to
BetoBoard accept direct application of various floor finishes including ceramic tiles, vinyl or hard
BetoBoard accept direct application of various floor finishes including ceramic tiles, vinyl or hard
Finishing Flexibility BetoBoard can accept most floor finishes bonded directly to the flooring panels.
The panels do not need to be primed prior to application of the adhesive and the floor finish, meaning the floor design is flexible with carpet, vinyl, laminate, timber, stone, and ceramic tiles.
Our Heavyweight Board for In and Outdoor
Suitable for Heavy Traffic
Our BetoBoard FB 32 is the perfect solution for large rooms where there is heavy traffic. Due to the tongue and groove connection of the panels with a size of 1200 x 600 mm and/or 600 x 600mm an absolutely even floor surface is created .
Improved living quality
- non-flammable (A1)
- easy processing
- various standard formats
- Board thickness of 10 - 40 mm possible *
- various coatings possible
- suitable for Heavy traffic
Tile Backer Board or Partition Board Fireclass A1 8-10-12mm
BetoBoard 8 -10-12 mm Tile Backer board is available in two sizes 1200x800mm or 600x1200
BetoBoard 8 -10-12 mm Tile Backer board is available in two sizes 1200x800mm or 600x1200
BetoBoard 8 -10-12 mm Tile Backer board is available in two sizes 1200x800mm or 600x1200
Mezzanine flooring• Balconies and loft conversions• Bathrooms and wetrooms
• Enhances underfloor heating systems
Suitable for
Renovation, fire protection, noise protection, impact sound insulation, thermal insulation, underfloor heating
BetoBoard straight edges tolerances are plus minus 1 mm
BetoBoard 8 -10-12 mm Tile Backer board is available in two sizes 1200x800mm or 600x1200
BetoBoard 8 -10-12 mm Tile Backer board is available in two sizes 1200x800mm or 600x1200
Finishing Flexibility BetoBoard can accept most floor finishes bonded directly to the flooring panels.
The panels do not need to be primed prior to application of the adhesive and the floor finish, meaning the floor design is flexible with carpet, vinyl, laminate, timber, stone, and ceramic tiles.
BetoBoard TB suitable for wet areas
Suitable for Heavy Traffic
Our BetoBoardr FB 32 is the perfect solution for large rooms where there is heavy traffic. Due to the tongue and groove connection of the panels with a size of 1200 x 600 mm and/or 600 x 600 an absolutely even floor surface is created .
Improved living quality
- non-flammable (A1)
- easy processing
- various standard formats
- Board thickness of 10 - 40 mm possible *
- various coatings possible
About Us
BetoBoard easy and safe to use
BetoBoard
fiber Cement screed elements consist of two 1fiber boards glued together. The two panels are offset from one another so that a 30 mm wide rebate is created.
Suitable for rooms with high levels of moisture, can be used for indoor and outdoor use Rooms with high levels of moisture, such as bathrooms, place high demands on the building material.
Construction Floor Boards A1 Class.
Various Board thickness possible
.
BetoBoard FB 28mm or 32 mm consists of two cement-bound lightweight concrete building boards.
They are
- Fiber Cement boards with effective fire and noise protection (airborne and impact sound)
- Optimal thermal insulation for a pleasant feeling of living with maximum energy efficiency
- Easy laying of floor coverings of any kind directly on the screed panels
- Perfectly suitable for laying on underfloor heating
- Cover area: 0.72 m² or 0,36m2 each
The BetoBoard is the best choice for renovating your floor. By laying the screed panels under your actual floor covering, you improve the feeling of living and protect your floor from various types of damage.
Improved living quality
The BetoBoard panels ensure optimum thermal insulation under your floor covering. The screed panels not only provide pleasant room warmth, but also reduce your heating costs at the same time. Normally these are caused by the escape of room heat. In addition, the gypsum fiber boards offer effective fire protection. Airborne and impact sound are also enormously reduced by the sound insulation.
Easy laying
The dry screed elements are particularly easy to use because you can lay the actual floor covering directly on Betoboards. They are suitable for all types of floor coverings
